Heavy duty shredder 1.500 mm 110 kw (or 90kW) for large plastic-wood-light metal scraps-tyres

2-SHAFT SHREDDER - HEAVY DUTY

The machine is constructed in sturdy carbon steel and is complete with a supporting structure (1.400 mm heigh) and a loading hopper prepared to receive material from a spider or a belt, size 2.500 x 1.500 x 1.200

Shredding chamber mm.1500 x 900

independent shafts 1.500 mm long

shafts are driven by independent electromechanical motors.

2 x 55 kW motors (or 2 x 45 kW)

The maximum installed power is used to absorb load peaks. Normally, absorption will settle at values around 50% of the installed power.

Shafts speed 13-15 rpm

N.20 knives 75 mm thick with 4 hooks

Automatic inversion on overload

Automatic lubrication pump

Tolerance : iron rods with a maximum thickness of 4 mm (up to 3%-4% of the total material)

Electrical panel with PLC

Cabinet dimensions: L 1800 mm, H 2000 mm, D 500 mm.

N.B. For ambient temperatures above +40 °C, the electrical panel must be located inside

a refrigerated control room (not included in this offer).
